Intelligent Smart House Control System Four Scene Panel Touch Screen Wall Switch

Basic Information
Place of Origin: China
Brand Name: RECEN
Certification: CE, ISO9001, SGS
Model Number: RC-SM-0010
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Cartons
Delivery Time: 5-10 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 sets per month
Detail Information
Product Name: : Zero Fire Switch. Product Size: : 86 × 86 × 32mm.
Power Supply Mode: : AC100-240V 50/60HZ. Working Temperature:: -10 ℃ ~ 50 ℃.
Communication Method: : ZigBee. Communication Distance: : 80-120m (empty And Unsheltered).
High Light:

smart home control system

,

home automation control systems


Product Description

Smart House Control Intelligent Home Touch Four Scene Panel Lighting Control




Product Profile



Ultra-thin touch series

Switch | Scene | Curtain motor



One-click toggle custom scene mode



Thickness 6.5mm creates extremely thin myth

The anti-surge switch strengthens the capacitive load capacity, minimizes the interference of the home power grid, prevents the instability of other equipment caused by switching lights, and effectively improves the life of LED lamps and lanterns.



Specification



Product name: Zero fire switch.
Product size: 86 × 86 × 32mm.
Power supply mode: AC100-240V 50/60HZ.
Working temperature: -10 ℃ ~ 50 ℃.
Communication method: ZigBee.
Communication distance: 80-120m (empty and unsheltered).

Single load: resistance ≤ 800W; inductance and capacitance ≤ 800W



Product name: Motor control panel.
Product size: 86 × 86 × 32mm.
Rated voltage: AC100-240V 50/60HZ.
Working temperature: -10 ℃ ~ 50 ℃.
Communication method: ZigBee.
Communication distance: 80-120m (empty and unsheltered).
Motor load: ≤ 200W.



Product name: Four-button scene.
Product size: 86 × 86 × 32mm.
Power supply mode: AC100-240V 50/60HZ.
Working temperature: -10 ℃ ~ 50 ℃.
Communication method: ZigBee.
Communication distance: 80-120m (empty and unsheltered).



Product name: LCD scene panel.
Product size: 86 × 86 × 32mm.
Screen size: 2.4 inches.
Product material: toughened glass.
Installation method: Wall-embedded installation (standard 86 pre-embedded box).
Mode of operation: touch button.
Rated voltage: AC100-240V 50/60Hz.
Communication method: ZigBee.
Communication distance: 80-120m (empty and unsheltered).
Working temperature: -10 ℃ ~ 50 ℃.



Intelligent Smart House Control System Four Scene Panel Touch Screen Wall Switch 0Intelligent Smart House Control System Four Scene Panel Touch Screen Wall Switch 1Intelligent Smart House Control System Four Scene Panel Touch Screen Wall Switch 2Intelligent Smart House Control System Four Scene Panel Touch Screen Wall Switch 3
